YD-CA4-100
Cassegrain Antenna
Cassegrain antenna YD-CA4-100 is a combined antenna, which is composed of two reflective surfaces and a feed, due to the realization of the feed posterior, greatly facilitates system integration, widely used in the field of satellite communications.
Product Category:
Cassegrain Antenna
Keywords:
Cassegrain Antenna
Product Manual:
Price
$ 2100
Inventory Remaining
999
Cassegrain antenna YD-CA4-100 is a combined antenna, which is composed of two reflective surfaces and a feed, due to the realization of the feed posterior, greatly facilitates system integration, widely used in the field of satellite communications.
The antenna can achieve a gain of more than 40dB, and by changing the feed characteristics, it can achieve linear polarization and circular polarization radiation characteristics.
Mechanical Outline
|
Parameter |
Minimum |
Typical |
Maximum |
|
Frequency |
200GHz |
|
220GHz |
|
Gain |
|
44dBi |
|
|
3 dB beamwidth |
|
1° |
|
|
Sidelobe level |
|
-20dB |
|
|
Return loss |
|
15dB |
|
|
Operating temperature |
-40 °C |
|
+85 °C |
|
Project |
Specification |
|
Antenna interface |
WR-4/UG387 |
|
Reflector Diameter |
100mm |
|
Antenna material |
Aluminum/copper |
|
Surface treatment |
Passivation/gold plating |
|
Weight |
133.645g |
